R19 E-Scooter – Technical Specifications

Product data

• Product name: Electric scooter

• Model: R19

Dimensions

• Size (L × W × H): 110 × 51 × 118 cm

• Folded size (L × W × H): 110 × 51 × 54 cm

Weight

• Net weight: 16 kg (35.3 lbs)

• Gross weight: 19.3 kg (42.5 lbs)

Mileage

• Maximum load: 150 kg (330 lbs)

• Recommended age: 16 years and over

• Speeds:

  • 12 km/h

  • 20 km/h

  • 25 km/h

• Range: approx. 30–35 km with 75 kg load

• Maximum gradient angle: 10–15%

• Protection class: IP54 (dust and splash protection)

• Charging time: approx. 6 hours

battery

• Nominal voltage: 36 V

• Maximum input voltage: 42 V

• Capacity: 11.4 Ah

• Battery management system:
  Protection against abnormal temperature, short circuit, undervoltage, overcurrent, overvoltage, overcharge and deep discharge

Motor

• Motor power: 500 W

charger

• Input voltage: 100–240 V~

• Output voltage: 42 V

• Output current: 2 A

equipment

• Tires: 10-inch honeycomb solid tires (maintenance-free)

• Suitable terrain: Flat cement or asphalt ground

• Braking system: Disc brake + Electronic brake
